1、high rack wire pay off → involucra → online drying (φ6.5 or φ5.5mm raw materials) → lz8/600stright drawing line → wash tank → sg740i-shaped wire take-up machine (φ6.5 or φ5.5mm stainless steel wire is drawed to φ1.8mm minimum)
3、annealing:wire pay off →electrolytic pickling →washing →20 tube natural gas annealing furnace →cooling tank →vertical wire take-up machine
4、fine drawing:high rack wire pay off → involucra → dry on line (≥ φ1.8mm raw material) → lz9/400stright drawing line → tension stand → wash tank → sg740i-shaped wheel take-up machine (stainless steel wire below φ3.5mm is drawed to φ0.5mm minimum)
5、annealing:wire pay off →electrolytic pickling →washing---20 tube annealing furnace →cooling tank →vertical wire take-up machine
6、fine drawing:
1、high rack wire pay off ---involucra → online drying (≤ φ1.2mm raw materials) → lz11/300stright drawing line → tension stand → wash tank → sg300i-shaped wire take-up machine (stainless steel wire below φ1.2mm is drawed to φ0.2mm minimum)
2、high rack wire pay off → lt15/300water tank drawing unit → tension stand → wash tank → sg300i-shaped wire take-up machine (stainless steel wire below φ1.2mm is drawed to φ0.2mm minimum)
